管道外壁自動噴砂機
◆適用性使用范圍 Applicable scope
管(guan)類(lei)類(lei)件,如:保(bao)溫(wen)鋼管(guan)、彈簧(huang)鋼、支撐桿(gan)(gan)、擠(ji)出機螺桿(gan)(gan)、較大(da)型柱(zhu)體(ti)、圓罐類(lei)、柱(zhu)體(ti)型鋁件;通過(guo)雙槍(可按符合要求多槍)及漩(xuan)風式(shi)吸(xi)塵器和光電(dian)子感受(shou)到技能,提(ti)高自己了(le)生(sheng)孩子吸(xi)收率及極大(da)的的少(shao)了(le)維護率。 (此門焊機需(xu)既定)
The kind of pipe workpieces, such as: steel pipe, round steel, bars, screw, large cylindrical, cylinder, round the plant; Adopt double gun (according to demand more gun) and new filter and light electricity function, improve the production efficiency and reduce the maintenance rate. (the model need to customize)
◆主要系統規格 Main technical parameters
|
廣州POS機應用 Model |
STR-1500管道外壁自動噴砂機 |
STR-1800輥傳動雙槍自動噴砂機 |
|
做工作艙大小 Working class size(mm) |
1000×900×900 |
1800×900×1000 |
|
整個機械長度 Complete machine size(mm) |
1200×900×2900 |
1900×900×2900 |
|
減少暖空氣源 Compressed air source |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
|
開關電源 Power |
220v 50Hz |
220v 50Hz |
|
交流變頻發電機變速器 Governor |
250W×2 |
250W×2 |
|
分離處理器同步電機 Separator motor |
380v 50Hz 4kw |
220v 50Hz 1.1kw |
|
分割器新風量 Air separator |
35m3/min |
35m3/min |
|
POS機體重 Machine weight |
900kg |
900kg |
