◆的產品特別 Product features
1. 設計的(de)概念(nian)趣味性,外型牢固,環保型使用效果非常好(hao);
2. 可變(bian)式(shi)漩風提取器(qi),能將常用爐料(liao)與細微塵土提取,好的(de)爐料(liao)再繼(ji)續動用;
3. 重要零(ling)(ling)結構件(jian)用到更優質(zhi)入(ru)口零(ling)(ling)件(jian)及(ji)運(yun)轉(zhuan)情況,利用耐用度長;
4. 粗加工零(ling)件面上平均;
5. 多工位器具設計方案;基本運行者可此外基本運行噴砂。按照雇主需要,待選擇手工或電腦自動 ;可按買家規定為您加工定制!
1. Novel design , beautiful shape, good environmental protection effect;
2. Adjustable cyclone separator, can be used with tiny dust separation, good abrasive continue to use;
3. The main components uses the high quality import parts, long service life;
4. Machining surface evenly;
5. Program design; An operator can also operate sandblasting. we can choose manual or automatic according to customer needs.
◆用于范圍之內 Applicable scope
板料,計算機底殼,聲響表面面板,雞蛋三明治(zhi)烤盤等三視圖及方體產品(pin)工件的噴砂(sha)加工廠。
Plate, the computer case, music panels, sandwich baking dish wait for plane and workpiece of sandblasting processing.
◆主耍工藝主要參數 Main technical parameters
|
器機款型 Model |
STR-多工位輸送式噴砂機 |
|
設備規格(ge)尺寸 Complete machine size(mm) |
3000×1000×1700 |
|
本職工作區域 Work space(mm) |
2000×1000×800 |
|
外運輸(shu)的尺(chi)寸 Conveying the size(mm) |
500×1000×1000(2件) |
|
清灰箱長寬高 Dedust box sizes(mm) |
600×600×1800 |
|
破乳器交流電動(dong)機(ji) Separator motor |
220V 50HZ 550W |
|
離(li)心離(li)心過濾器(qi)風速 Separator air volume |
8.5m3/min |
|
壓(ya)解(jie)冷空(kong)氣源 Compressed air source |
2-8bar(kg/cm2) |
|
噴槍 Spray gun |
2把 |
|
照明 Floodlight |
兩盞30W防火燈 |
|
設(she)備自重 Machine weight |
550kg |
